Engineering Plastic UHMWPE Borated Polyethylene Sheet Boron Board With 5% Boron

Certification
China Tangyin Taixing Engineering Plastics Co., Ltd. certification
China Tangyin Taixing Engineering Plastics Co., Ltd. certification
I'm Online Chat Now

Engineering Plastic UHMWPE Borated Polyethylene Sheet Boron Board With 5% Boron

Engineering Plastic UHMWPE Borated Polyethylene Sheet Boron Board With 5% Boron
Engineering Plastic UHMWPE Borated Polyethylene Sheet Boron Board With 5% Boron Engineering Plastic UHMWPE Borated Polyethylene Sheet Boron Board With 5% Boron Engineering Plastic UHMWPE Borated Polyethylene Sheet Boron Board With 5% Boron Engineering Plastic UHMWPE Borated Polyethylene Sheet Boron Board With 5% Boron

Large Image :  Engineering Plastic UHMWPE Borated Polyethylene Sheet Boron Board With 5% Boron

Product Details:
Place of Origin: China
Brand Name: TaiXing
Certification: ISO9001
Model Number: PE Borated Polyethylene Sheet Boron
Payment & Shipping Terms:
Minimum Order Quantity: 50 kilograms
Price: Negotiable
Packaging Details: Wooden Crate of Pallet
Delivery Time: 15-20 days after deposit received
Payment Terms: T/T, Western Union
Supply Ability: 5000 /Kilograms per Month

Engineering Plastic UHMWPE Borated Polyethylene Sheet Boron Board With 5% Boron

Description
Item:: Ngineering Plastic UHMWPE Borated Polyethylene Sheet Boron Board Material: 5% Borated High Density Polyethylene(HDPE)
Color:: Natural Colour Size:: 1220mm*2440 Mm
Elemental Boron: 5% By Weight Water Absorption: <0.01%
Processing Service:: Cutting, Moulding
High Light:

PE Borated Polyethylene Sheet Boron

,

UHMWPE Borated Polyethylene Sheet

,

Borated Polyethylene Sheet Boron Board

        Engineering Plastic UHMWPE Borated Polyethylene Sheet Boron Board with 5% Boron
Boron polyethylene shield (borated polyethylene shielding box) of boron polyethylene materials according to use need to customize, used for shielding radioactive source radiation shielding, in boron polyethylene shield, boron can absorb effect, of boron neutron reaction cross section is larger, in has not happened before the reaction of hydrogen boron neutron can be fully absorbed, Thus play a complete shielding role.


Engineering Plastic UHMWPE Borated Polyethylene Sheet Boron Board With 5% Boron 0

Boroned Polyethylene Board Advantages:

  1. Resistance to wear, because of its unique molecular structure, wear resistance is higher than general metal plastic products.
  2. Not sticky, small friction coefficient, surface tension of polarity, so no affinity with the common material, therefore not easy adhesion scaling.
  3. Small friction coefficient, good self-lubrication, small flow resistance.
  4. Chemical corrosion resistance: resistant to sulfuric acid, nitric acid and other strong oxidizer outside of acid, alkali, salt medium.
  5. Good resistance to impact, even at low temperatures, fracture by strong.
  6. Electrical insulation, good electrical insulation, high insulation resistance.



Product Specification:


Instead of a portable shield, the plate is used as a gasket and electrical insulation in various hollow structures or devices whose housing is protected by a casing (the plate is placed between the housing and the casing or is tightly lined on the outside of the object).



Project Unit Test Result
Notched Izod Impact ft. lbs/in.2 No Break
Vicat Softening Temp. ºC (ºF) 89ºC (192ºF)
Tensile Strength @ Break % >140
Elongation @ Yield p.s.i. >300
Shore Harness ShoreD 64
Flexural Modulus p.s.i. 3000



Engineering Plastic UHMWPE Borated Polyethylene Sheet Boron Board With 5% Boron 1


The company's standard boron content ranges from 2% to 30%, which can be customized according to customer use and needs. Boron carbide, boron trioxide, borax, boric acid, lead powder, lithium carbonate, etc. can be added to it. Size and thickness The company's design department has a specific splicing plan, and the radiation shielding performance will not be damaged after splicing.





Length x Width x Thickness ( mm ) Length x Width x Thickness (mm)
700 х 500 х 10 1000 х 500 х 10
700 х 500 х 20 1000 х 500 х 20
700 х 500 х 25 1000 х 500 х 25
700 х 500 х 30 1000 х 500 х 30
700 х 500 х 40 1000 х 500 х 40
700 х 500 х 50 1000 х 500 х 50
700 х 500 х 60 1000 х 500 х 60
700 х 500 х 65 1000 х 500 х 65
700 х 500 х 70 1000 х 500 х 70


Engineering Plastic UHMWPE Borated Polyethylene Sheet Boron Board With 5% Boron 2





Why Choose Boron-polyethylene board :


First of all, borated polyethylene is used in the nuclear power industry — to protect employees from radiation caused by:

  • fast and thermal neutrons;
  •  alpha and gamma radiation (primary and secondary).

Speaking generally, almost all structural divisions of nuclear power need borated polyethylene sheets:

  • nuclear power plants;
  • nuclear - powered ships, etc.

BPE sheets with the right distance from the source of ionizing radiation, dimensions, boron concentration and some other indicators can both delay background radiation and active radiation by 100%, and reduce their intensity to health-safe values.



The second area of application of borated polyethylene is medical institutions — where there is a risk of radiation exposure: X-ray rooms, treatment rooms using fast neurons, rooms for fluorography, radiation therapy for cancer, etc.



The third area of demand is the creation of a safe environment in laboratories using radioactive installations and/or components.



Finally, borated polyethylene boards are purchased by ordinary citizens for household purposes if their homes are located near radio-emitting objects or the radio background is increased due to poor-quality building materials of walls, ceiling, etc.





FAQ:


Q1: Are you a trading company or manufacturer?
A1: We are manufacture to produce boron polyethylene plate.


Q2: What is your MOQ of boron polyethylene plate?
A2: It depends on the stock we have and the size you need.


Q3: Q: How soon can I get the goods?
A3: Generally, 5-10 days with stock and 15-20 days without stock, according to quantity.



4.Q: How about your after-sales service?
A4: We have A dedicated after sales tracker, any need can contact us at any time.


 Q5: How can I get sample from you
 A5: Just send your requirement and we will send you the samples accordingly by DHL,UPS,TNT or others
