Neutron Source Shielding Material 30% Boron Content Borated Polyethylene Board

Neutron Source Shielding Material 30% Boron Content Borated Polyethylene Board
Neutron Source Shielding Material 30% Boron Content Borated Polyethylene Board Neutron Source Shielding Material 30% Boron Content Borated Polyethylene Board Neutron Source Shielding Material 30% Boron Content Borated Polyethylene Board Neutron Source Shielding Material 30% Boron Content Borated Polyethylene Board

Large Image :  Neutron Source Shielding Material 30% Boron Content Borated Polyethylene Board

Product Details:
Place of Origin: China
Brand Name: TaiXing
Certification: ISO9001
Model Number: 30% Boron Content Borated Polyethylene Board
Payment & Shipping Terms:
Minimum Order Quantity: 50 kilograms
Price: Negotiable
Packaging Details: Wooden Crate of Pallet
Delivery Time: 15-20 days after deposit received
Payment Terms: T/T, Western Union
Supply Ability: 5000 /Kilograms per Month

Neutron Source Shielding Material 30% Boron Content Borated Polyethylene Board

Description
Item:: Neutron Source Shielding Material 30% Boron Content Borated Polyethylene Board Material: 100% Virgin PE
Color:: Natural Black Size: 1220mm*2440 Mm
Elemental Boron: Boron 30% By Weight Function: Neutron Source Shielding
Processing Service:: Cutting, Moulding
High Light:

30% Boron Content Borated Polyethylene Board

,

30% Borated Polyethylene Board

,

borated polyethylene neutron shielding

      Neutron Source Shielding Material 30% Boron Content Borated Polyethylene Board


 Borated polyethylene sheet is a product specially designed for nuclear and radiation shielding application, its neutron shield properties have been tested and certified. As same as other shielding materials, this material can produce y-ray under the action of neutron, and y-ray dose is second grade relative to shielding neutron. Borated polyethylene costs low and light-weighted, so it is the best material to replace lead to shield neutron. The boron content is from 2% to 30% by weight according to applications and customers' requirements.


Neutron Source Shielding Material 30% Boron Content Borated Polyethylene Board 0

Boroned Polyethylene Board Advantages:

  • It has good catalytic activity, little corrosion to equipment, and will not cause environmental pollution.
  • Good radiation resistance, can meet the needs of different energy levels of radiation occasions.
  • It has good machining performance and aging resistance.



Product Specification:


Instead of a portable shield, the plate is used as a gasket and electrical insulation in various hollow structures or devices whose housing is protected by a casing (the plate is placed between the housing and the casing or is tightly lined on the outside of the object).



Project Unit Test Result
Notched Izod Impact ft. lbs/in.2 No Break
Vicat Softening Temp. ºC (ºF) 89ºC (192ºF)
Tensile Strength @ Break % >140
Elongation @ Yield p.s.i. >300
Shore Harness ShoreD 64
Flexural Modulus p.s.i. 3000



Neutron Source Shielding Material 30% Boron Content Borated Polyethylene Board 1


PE boron-containing board is mainly used to protect neutrons and gamma rays, with good radiation resistance, no activation products, low gamma ray energy, high mechanical properties, corrosion resistance, non-toxic and tasteless, impact resistance, low temperature resistance and chemical stability.



Length x Width x Thickness ( mm ) Length x Width x Thickness (mm)
700 х 500 х 10 1000 х 500 х 10
700 х 500 х 20 1000 х 500 х 20
700 х 500 х 25 1000 х 500 х 25
700 х 500 х 30 1000 х 500 х 30
700 х 500 х 40 1000 х 500 х 40
700 х 500 х 50 1000 х 500 х 50
700 х 500 х 60 1000 х 500 х 60
700 х 500 х 65 1000 х 500 х 65
700 х 500 х 70 1000 х 500 х 70


Neutron Source Shielding Material 30% Boron Content Borated Polyethylene Board 2





Why Choose Boron-polyethylene board :


First of all, borated polyethylene is used in the nuclear power industry — to protect employees from radiation caused by:

  • fast and thermal neutrons;
  •  alpha and gamma radiation (primary and secondary).

Speaking generally, almost all structural divisions of nuclear power need borated polyethylene sheets:

  • nuclear power plants;
  • nuclear - powered ships, etc.

BPE sheets with the right distance from the source of ionizing radiation, dimensions, boron concentration and some other indicators can both delay background radiation and active radiation by 100%, and reduce their intensity to health-safe values.



The second area of application of borated polyethylene is medical institutions — where there is a risk of radiation exposure: X-ray rooms, treatment rooms using fast neurons, rooms for fluorography, radiation therapy for cancer, etc.



The third area of demand is the creation of a safe environment in laboratories using radioactive installations and/or components.



Finally, borated polyethylene boards are purchased by ordinary citizens for household purposes if their homes are located near radio-emitting objects or the radio background is increased due to poor-quality building materials of walls, ceiling, etc.





FAQ:


Q1: Are you a trading company or manufacturer?
A1: We are manufacture to produce boron polyethylene plate.


Q2: What is your MOQ of boron polyethylene plate?
A2: It depends on the stock we have and the size you need.


Q3: Q: How soon can I get the goods?
A3: Generally, 5-10 days with stock and 15-20 days without stock, according to quantity.



Q4: How about your after-sales service?
A4: We have A dedicated after sales tracker, any need can contact us at any time.
