Impact Resistant HDPE Pipe Idler Polymer Roller Belt Conveyor Troughing Roller

Certification
China Tangyin Taixing Engineering Plastics Co., Ltd. certification
China Tangyin Taixing Engineering Plastics Co., Ltd. certification
I'm Online Chat Now

Impact Resistant HDPE Pipe Idler Polymer Roller Belt Conveyor Troughing Roller

Impact Resistant HDPE Pipe Idler Polymer Roller Belt Conveyor Troughing Roller
Impact Resistant HDPE Pipe Idler Polymer Roller Belt Conveyor Troughing Roller Impact Resistant HDPE Pipe Idler Polymer Roller Belt Conveyor Troughing Roller Impact Resistant HDPE Pipe Idler Polymer Roller Belt Conveyor Troughing Roller Impact Resistant HDPE Pipe Idler Polymer Roller Belt Conveyor Troughing Roller

Large Image :  Impact Resistant HDPE Pipe Idler Polymer Roller Belt Conveyor Troughing Roller

Product Details:
Place of Origin: China
Brand Name: TaiXing
Certification: ISO9001
Model Number: Polymer Roller Belt Conveyor Troughing Roller
Payment & Shipping Terms:
Minimum Order Quantity: 500 pieces
Price: Negotiable
Packaging Details: Wooden Crate of Pallet
Delivery Time: 15-20 days after deposit received
Payment Terms: T/T, Western Union
Supply Ability: 500000 / pieces per Month

Impact Resistant HDPE Pipe Idler Polymer Roller Belt Conveyor Troughing Roller

Description
Item:: Impact Resistant HDPE Pipe Idler Polymer Roller Belt Conveyor Troughing Roller Material: PE Virgin 100%
Color:: Blue,Black Or Customized Size:: Dia: 76-194mm
Structure: Ordinary Roller Process: Mould Pressing
Application: Chemical Industry, Grain Transportation, Mining Transport, Power Plant
High Light:

Polymer Roller Belt Conveyor Troughing Roller

,

Polymer troughing idler roller

,

HDPE impact idler roller

High Seal Noise Reduction UHMWPE Plastic Troughing Roller of Conveyor Idlers



Impact Resistant HDPE Pipe Idler Polymer Roller Belt Conveyor Troughing Roller

polyethylene plastic belt conveyor roller is a high-tech product, which consists of uhmwpe pipe,metal bearing, metal shaft , plastic bearing housing , sealing ring and so on . Compared with metal roller , uhmwpe plastic roller has many obvious advantages in performance.



Impact Resistant HDPE Pipe Idler Polymer Roller Belt Conveyor Troughing Roller 0



Plastic conveyor rollers Features:



Durable for over 3 years



Withstand 30,000 hours of rotation, super long life



Better than metal rollers



Lightweight silenced rain resistance reduces belt wear



Product Specification:


UHMWPE Conveyor Roller have many features like lightweight, small wear, anti-UV, anti-static, labyrinth seal, high self-lubricating property, it can work well with belt. While UHMW Idler has high impact resistance and tenacity to bear the impact and shake.



Impact Resistant HDPE Pipe Idler Polymer Roller Belt Conveyor Troughing Roller 1



Outer Diameter

D1(mm)





Shaft Diameter

D2 (mm)



Customized(mm)

Bearing Type

(HRB/LYC/SKF)

Bearing size

(mm)

Dia76 Dia20

Custom Length:

150-2000
L1,L2,L3,L4,L5



Spindle Head Custom: Milling, Punch, Thread

6204 20*47*14
Dia89 Dia20 6204 20*47*14
Dia102 Dia20 6204 20*47*14
Dia25 6205 25*52*15
Dia108 Dia20 6304 25*52*15
Dia25 6205 25*52*15
Dia114 Dia25 6205 25*52*15
Dia127 Dia25 6305 25*62*17
Dia30 6306 30*72*19
Dia133 Dia25 6305 25*62*17
Dia140 Dia25 6305 25*62*17
Dia152 Dia35 6307 35*80*21
Dia159 Dia35 6307 35*80*21





Impact Resistant HDPE Pipe Idler Polymer Roller Belt Conveyor Troughing Roller 2



UHMWPE conveyor belt roller has a novel structure, reliability seal, and advanced material selection. Rollers and housing are made of ultra-High Molecular Weight Polyethylene (UHMWPE) which has anti-friction self-lubrication, impact resistance, anti-adhesion, and anti-corrosion, resistant to aging, and other characteristics.



Impact Resistant HDPE Pipe Idler Polymer Roller Belt Conveyor Troughing Roller 3







Characteristics of  plastic Conveying roller:


1. High-wear resistance is seven times the wear resistance of steel and four times that of PTFE.



2. High impact resistance two times impact resistance than PC, five times than ABS.



3. Self-lubrication is the same as PTFE, better than steel and brass appended lubricating oil.



4. Anti-corrosion resistance, stable chemicals property and can endure the corrosion of all kinds of corrosive medium and organic solvent in certain rang of temperature and humidity.



5. Non-sticking the smooth surface of the product hardly affixes other material.



6. Low-temperature resistance in (-196), it still has the prolongation and high tensile strength.



7. Non-toxic and clean property.



Packaging & Shipping


Packing Details: Standard wooden package box or as per your requirements.
Delivery Details: 15-25 days according to your early payment.



Impact Resistant HDPE Pipe Idler Polymer Roller Belt Conveyor Troughing Roller 4



FAQ:




Q1: Are you a trading company or manufacturer?
A1: We are manufacture to produce plastic conveyor roller.


Q2: What is your MOQ of plastic conveyor roller?
A2: It depends on the stock we have and the size you need.


Q3: What color of plastic conveyor rolleryou can produce?
A3: Our common colors are black and blue. we can produce other colors according to your requirement too.


Q4: Could you provide a product customization service?
A4: Yes, and it's better to get your drawing or idea of it.
