Anti Corrosion UHMW PE Belt Conveyor Idler Roller For Conveyor Carrier Roller

Certification
China Tangyin Taixing Engineering Plastics Co., Ltd. certification
China Tangyin Taixing Engineering Plastics Co., Ltd. certification
I'm Online Chat Now

Anti Corrosion UHMW PE Belt Conveyor Idler Roller For Conveyor Carrier Roller

Anti Corrosion UHMW PE Belt Conveyor Idler Roller For Conveyor Carrier Roller
Anti Corrosion UHMW PE Belt Conveyor Idler Roller For Conveyor Carrier Roller Anti Corrosion UHMW PE Belt Conveyor Idler Roller For Conveyor Carrier Roller Anti Corrosion UHMW PE Belt Conveyor Idler Roller For Conveyor Carrier Roller Anti Corrosion UHMW PE Belt Conveyor Idler Roller For Conveyor Carrier Roller

Large Image :  Anti Corrosion UHMW PE Belt Conveyor Idler Roller For Conveyor Carrier Roller

Product Details:
Place of Origin: China
Brand Name: TaiXing
Certification: ISO9001
Model Number: PE Belt Conveyor Idler Roller
Payment & Shipping Terms:
Minimum Order Quantity: 1000 kilograms
Price: Negotiable
Packaging Details: Wooden Crate of Pallet
Delivery Time: 15-20 days after deposit received
Payment Terms: T/T, Western Union
Supply Ability: 500000 /Kilograms per Month

Anti Corrosion UHMW PE Belt Conveyor Idler Roller For Conveyor Carrier Roller

Description
Item: UHMW PE Belt Conveyor Idler Roller For Conveyor Carrier Roller Material: UHMWPE
Color: Blue,Black Or Customized Size: Dia: 76-194mm
Structure: Ordinary Roller Bearing Type: Double Sealed Bearing
Process: Mould Pressing
High Light:

PE Belt Conveyor Idler Roller

,

UHMW PE Plastic Conveyor Rollers

,

UHMWPE Belt Conveyor Idler Roller

Anti-Corrosion UHMW PE Belt Conveyor Idler Roller For Conveyor Carrier Roller




Plastic rollers are designed to convey lightweight loads. When combined with stainless steel bearings and spindles they are perfect for use in humid or wash-down environments. A sealed bearing roller is also available for arduous applications and can be used as a belt return roller.



Anti Corrosion UHMW PE Belt Conveyor Idler Roller For Conveyor Carrier Roller 0



Plastic  conveyor rollers Features:



  • Free running capability to convey very lightweight loads
  • Low cost alternative to stainless steel tube rollers
  • Plastic conveyor rollers are available in either grey and blue.
  • Ideal for use in humid, wet or wash-down environments
  • Non-marking benefits when in contact with the white top surface of flat or modular belts



Product Specification:


Roller for Conveyor market well-known brands, a variety of standard and non-standard roller service nearly a thousand large customers.



Anti Corrosion UHMW PE Belt Conveyor Idler Roller For Conveyor Carrier Roller 1



Outer Diameter

D1(mm)





Shaft Diameter

D2 (mm)



Customized(mm)

Bearing Type

(HRB/LYC/SKF)

Bearing size

(mm)

Dia76 Dia20

Custom Length:

150-2000
L1,L2,L3,L4,L5



Spindle Head Custom: Milling, Punch, Thread

6204 20*47*14
Dia89 Dia20 6204 20*47*14
Dia102 Dia20 6204 20*47*14
Dia25 6205 25*52*15
Dia108 Dia20 6304 25*52*15
Dia25 6205 25*52*15
Dia114 Dia25 6205 25*52*15
Dia127 Dia25 6305 25*62*17
Dia30 6306 30*72*19
Dia133 Dia25 6305 25*62*17
Dia140 Dia25 6305 25*62*17
Dia152 Dia35 6307 35*80*21
Dia159 Dia35 6307 35*80*21





Anti Corrosion UHMW PE Belt Conveyor Idler Roller For Conveyor Carrier Roller 2



Our systems are widely used to transport all sorts of products – from corrosive substances, foodstuffs, heavy loads, dirty applications and material handling; we are able to offer plastic conveyor rollers that are exactly right for your intended use.



Anti Corrosion UHMW PE Belt Conveyor Idler Roller For Conveyor Carrier Roller 3







Characteristics of  plastic Conveying roller:


1. High-wear resistance is seven times the wear resistance of steel and four times that of PTFE.



2. High impact resistance two times impact resistance than PC, five times than ABS.



3. Self-lubrication is the same as PTFE, better than steel and brass appended lubricating oil.



4. Anti-corrosion resistance, stable chemicals property and can endure the corrosion of all kinds of corrosive medium and organic solvent in certain rang of temperature and humidity.



5. Non-sticking the smooth surface of the product hardly affixes other material.



6. Low-temperature resistance in (-196), it still has the prolongation and high tensile strength.



7. Non-toxic and clean property.



Application:


PE conveyor roller is widely used in the original dock transporting places where dust is bigger and the environment has high corrosive , such as mining , power , steel , stone materials factory , cement and coking plant , coal washing factory , salt plant , alkali plant , fertilizer factory , dock and so on .



Anti Corrosion UHMW PE Belt Conveyor Idler Roller For Conveyor Carrier Roller 4



FAQ:


Q1: What is the main size of your HDPE /UHMWPE conveyor roller?
A1:φ89,φ102,φ108,φ114,φ127,φ133,φ140,φ152,φ159, The length could be customized. So please do not worry about the size.

Q2: What color of plastic conveyor rolleryou can produce?
A2: Our common colors are black and blue. we can produce other colors according to your requirement too.

Q3: Is there any warranty on the quality of your product?
A3: Please don't worry about that, we have 20 years of experience in producing PE conveyor roller, our products widely used in Europe, the America and other countries.

Q4: Is the sample available before mass production?
A4: Yes, a small block sample is free but the freight is by your side; If the sample size is the same as the mass production order, the customer needs to pay the sample cost and freight and we will return the cost after placing the order here.
