Wear Resistant Light Weight UHMWPE Idler Roller For Coal Mining Ports Belt Conveyor

Wear Resistant Light Weight UHMWPE Idler Roller For Coal Mining Ports Belt Conveyor
Wear Resistant Light Weight UHMWPE Idler Roller For Coal Mining Ports Belt Conveyor Wear Resistant Light Weight UHMWPE Idler Roller For Coal Mining Ports Belt Conveyor Wear Resistant Light Weight UHMWPE Idler Roller For Coal Mining Ports Belt Conveyor Wear Resistant Light Weight UHMWPE Idler Roller For Coal Mining Ports Belt Conveyor

Large Image :  Wear Resistant Light Weight UHMWPE Idler Roller For Coal Mining Ports Belt Conveyor

Product Details:
Place of Origin: China
Brand Name: TaiXing
Certification: ISO9001
Model Number: UHMWPE Idler Roller
Payment & Shipping Terms:
Minimum Order Quantity: 1000 kilograms
Price: Negotiable
Packaging Details: Wooden Crate of Pallet
Delivery Time: 15-20 days after deposit received
Payment Terms: T/T, Western Union
Supply Ability: 500000 /Kilograms per Month

Wear Resistant Light Weight UHMWPE Idler Roller For Coal Mining Ports Belt Conveyor

Description
Product Name: Light Weight UHMWPE Idler Roller For Coal Mining Ports Belt Conveyor Material: PE Virgin 100%
Color: Blue,Black Or Customized Size: Dia: 76-194mm
Type: Grooved Conveyor Idler Structure: Ordinary Roller
Advantage: Wear And Corrosion Resistance
High Light:

UHMWPE Idler Roller

,

Wear Resistant UHMWPE Idler Roller

,

impact roller for belt conveyor

Light Weight UHMWPE Idler Roller For Coal Mining Ports Belt Conveyor

Wear Resistant Light Weight UHMWPE Idler Roller For Coal Mining Ports Belt Conveyor

Light-weight and durable, plastic conveyor rollers are the product of choice for a growing number of companies across the country. UHMW conveyor rollers are often cheaper than their metal equivalents; the construction of modern plastics means that in many cases, plastic rollers for conveyors provide a material that’s as tough and lasts as long as a non-plastic alternative.



Wear Resistant Light Weight UHMWPE Idler Roller For Coal Mining Ports Belt Conveyor 0



Plastic  conveyor rollers Features:



  • Free running capability to convey very lightweight loads
  • Low cost alternative to stainless steel tube rollers
  • Plastic conveyor rollers are available in either grey and blue.
  • Ideal for use in humid, wet or wash-down environments
  • Non-marking benefits when in contact with the white top surface of flat or modular belts



Product Specification:


Roller for Conveyor market well-known brands, a variety of standard and non-standard roller service nearly a thousand large customers.



Wear Resistant Light Weight UHMWPE Idler Roller For Coal Mining Ports Belt Conveyor 1



Outer Diameter

D1(mm)





Shaft Diameter

D2 (mm)



Customized(mm)

Bearing Type

(HRB/LYC/SKF)

Bearing size

(mm)

Dia76 Dia20

Custom Length:

150-2000
L1,L2,L3,L4,L5



Spindle Head Custom: Milling, Punch, Thread

6204 20*47*14
Dia89 Dia20 6204 20*47*14
Dia102 Dia20 6204 20*47*14
Dia25 6205 25*52*15
Dia108 Dia20 6304 25*52*15
Dia25 6205 25*52*15
Dia114 Dia25 6205 25*52*15
Dia127 Dia25 6305 25*62*17
Dia30 6306 30*72*19
Dia133 Dia25 6305 25*62*17
Dia140 Dia25 6305 25*62*17
Dia152 Dia35 6307 35*80*21
Dia159 Dia35 6307 35*80*21





Wear Resistant Light Weight UHMWPE Idler Roller For Coal Mining Ports Belt Conveyor 2



UHMWPE Conveyor Roller have many features like lightweight, small wear, anti-UV, anti-static, labyrinth seal, high self-lubricating property, it can work well with belt. While UHMW Idler has high impact resistance and tenacity to bear the impact and shake.



Wear Resistant Light Weight UHMWPE Idler Roller For Coal Mining Ports Belt Conveyor 3







Characteristics of  plastic Conveying roller:


1. High-wear resistance is seven times the wear resistance of steel and four times that of PTFE.



2. High impact resistance two times impact resistance than PC, five times than ABS.



3. Self-lubrication is the same as PTFE, better than steel and brass appended lubricating oil.



4. Anti-corrosion resistance, stable chemicals property and can endure the corrosion of all kinds of corrosive medium and organic solvent in certain rang of temperature and humidity.



5. Non-sticking the smooth surface of the product hardly affixes other material.



6. Low-temperature resistance in (-196), it still has the prolongation and high tensile strength.



7. Non-toxic and clean property.



Application:


PE conveyor roller is widely used in the original dock transporting places where dust is bigger and the environment has high corrosive , such as mining , power , steel , stone materials factory , cement and coking plant , coal washing factory , salt plant , alkali plant , fertilizer factory , dock and so on .



Wear Resistant Light Weight UHMWPE Idler Roller For Coal Mining Ports Belt Conveyor 4



FAQ:


Q1: What is the main size of your HDPE /UHMWPE conveyor roller?
A1:φ89,φ102,φ108,φ114,φ127,φ133,φ140,φ152,φ159, The length could be customized. So please do not worry about the size.



Q2: What color of plastic conveyor rolleryou can produce?
A2: Our common colors are black and blue. we can produce other colors according to your requirement too.


Q3:Do you make a customized logo on the HDPE/UHMWPE conveyor rollers?
A4: Yes, we do. Just send your artwork for the logo. We will print the logo on the seals as your request.



Q4: Could you provide a product customization service?
A4: Yes, and it's better to get your drawing or idea of it.
