Polyethylene Conveyor Chain Guides Wear Resistant UHMWPE Linear Guide Rail

Polyethylene Conveyor Chain Guides Wear Resistant UHMWPE Linear Guide Rail
Polyethylene Conveyor Chain Guides Wear Resistant UHMWPE Linear Guide Rail Polyethylene Conveyor Chain Guides Wear Resistant UHMWPE Linear Guide Rail Polyethylene Conveyor Chain Guides Wear Resistant UHMWPE Linear Guide Rail Polyethylene Conveyor Chain Guides Wear Resistant UHMWPE Linear Guide Rail

Large Image :  Polyethylene Conveyor Chain Guides Wear Resistant UHMWPE Linear Guide Rail

Product Details:
Place of Origin: China
Brand Name: TaiXing
Certification: ISO9001
Model Number: UHMWPE Linear Guide Rail
Payment & Shipping Terms:
Minimum Order Quantity: 100 kilograms
Price: Negotiable
Packaging Details: Wooden Crate of Pallet
Delivery Time: 15-20 days after deposit received
Payment Terms: T/T, Western Union
Supply Ability: 500000 /Kilograms per Month

Polyethylene Conveyor Chain Guides Wear Resistant UHMWPE Linear Guide Rail

Description
Item:: Conveyor Plastic UHMWPE Chain Guide Track Rail Material: PE Virgin 100%
Color:: White,Green,Blue Customized Size: Customized
Thickness:: 6-200mm Feature: Wear Resistance
Application:: Corrosion-resistant And Wear-resistant Mechanical Parts
High Light:

UHMWPE Linear Guide Rail

,

Polyethylene Linear Guide Rail

,

Polyethylene Conveyor Chain Guides

Polyethylene Conveyor Chain Guides Wear Resistant UHMWPE Linear Guide Rail


UHMW guide rails can withstand the corrosion of various corrosive media and organic solvents within a certain temperature and humidity range. The polyethylene guide rail has high anti-adhesion, the surface of the guide rail is not easy to bond with other materials, and it is non-toxic and tasteless.

Polyethylene Conveyor Chain Guides Wear Resistant UHMWPE Linear Guide Rail 0



Polyethylene chain guide Features:

  • Abrasion resistance
  • Excellent self-lubricating performance
  • High impact strength
  • Excellent chemical resistance
  • Non-toxic and tasteless
  • Very low water absorption



Product Specification:




 Product Name

  High Density Polyethylene Plastic HDPE Sheet
 Material

  UHMWPE/ HDPE



 Size





size can also be cut into small piece depend on your usage


 Thickness

  6-200 mm



Impact Strength

  ≥140 KJ/m2



Water Absorption

<0.01%

Compressive Strength ≥30 Mpa
Ball Indentation Hardness ≥20N/mm2
Abrasion Loss 3.8×10-4G/cm2
Heat Distortion Temperature 85°C



Polyethylene Conveyor Chain Guides Wear Resistant UHMWPE Linear Guide Rail 1



UHMWPE material has exceptionally low coefficient of friction offering superb sliding properties and is one of the best plastics for wear/abrasion resistance meanwhile tough and impact resistant even at cryogenic temperatures. As a result, it is definite that UHMW polyethylene is a wonderful engineering plastic that can solve many problems that other engineering plastics cannot.



Polyethylene Conveyor Chain Guides Wear Resistant UHMWPE Linear Guide Rail 2





Why Choose UHMWPE Guide Rails:


High resistance to abrasion and mechanical wearing.


Resistance to absorption of liquid substances.


Low coefficient of sliding.


Noise reduction up to 90%.


Self-lubricating properties.


Elimination of vibrations.


Extreme resistance to impacts and ruptures.


Very high resistance to chemicals.


Corrosion resistance.


Good electrical insulation properties without maintenance.



About Us:


   Tangyin Taixing Engineering Plastic Co., Ltd. is located in Tengfei road, Yigou town, Tangyin county, Henan. We have gained many professional certificates with 20 years of experience.

    We are always dedicated to Providing high-performance goods and Producing new products for our customers. Mainly produce and sell UHMWPE sheet, UHMWPE Liner Sheet,Conveyor Roller ,Cutting board, Outrigger pad, ground mat. Our products sell well in domestic and international markets, such as the United States,Australia, Singapore, Pakistan, Thailand,South America etc, and are favorably appraised by clients.
