Customized Anti Impact Marine Fender Pad Uhmwpe / Hdpe

Certification
China Tangyin Taixing Engineering Plastics Co., Ltd. certification
China Tangyin Taixing Engineering Plastics Co., Ltd. certification
I'm Online Chat Now

Customized Anti Impact Marine Fender Pad Uhmwpe / Hdpe

Customized Anti Impact Marine Fender Pad Uhmwpe / Hdpe
Customized Anti Impact Marine Fender Pad Uhmwpe / Hdpe Customized Anti Impact Marine Fender Pad Uhmwpe / Hdpe Customized Anti Impact Marine Fender Pad Uhmwpe / Hdpe Customized Anti Impact Marine Fender Pad Uhmwpe / Hdpe Customized Anti Impact Marine Fender Pad Uhmwpe / Hdpe

Large Image :  Customized Anti Impact Marine Fender Pad Uhmwpe / Hdpe

Product Details:
Place of Origin: China
Brand Name: TaiXing
Certification: ISO9001
Model Number: UHMWPE Dock Cone Ship Fender Panel Board
Payment & Shipping Terms:
Minimum Order Quantity: 50 pieces
Price: Negotiable
Packaging Details: Wooden Crate of Pallet
Delivery Time: 15-20 days after deposit received
Payment Terms: T/T, Western Union
Supply Ability: 50000 /pieces per Month

Customized Anti Impact Marine Fender Pad Uhmwpe / Hdpe

Description
Item: UHMWPE Plastic Dock Cone Ship Fender Panel Board Material: 100% Virgin PE
Color: Blue, Black, Yellow Size: 1220mm*2440 Mm
Surface: Smooth Processing Service:: Cutting, Moulding
Usage: Wharf Use
High Light:

customized marine fender pad

,

anti impact marine fender pad

,

anti impact uhmw fender


Impingement plate is in a structure with the inclined periphery and the circular arc double turning corners in the transition fit. It can reduce the friction force between a ship body and the surface of the rubber fender, reduce the surface pressure exerted on a ship side board, reduce the mooring shearing force, and improve the service life of the PE fender.

Customized Anti Impact Marine Fender Pad Uhmwpe / Hdpe 0
 Customized Anti Impact Marine Fender Pad Uhmwpe / Hdpe 1

PE Marine Fenders Advantages:

PE Marine Fenders Facing Pad provide the benefits of higher wear resistance (even greater than steel) and lower maintenance; as they do not split or rot and are fully resistant to infestation from marine borers.
The low friction coefficient and high abrasion resistance of UHMWPE  provides an ultra smooth surface for the vessel to slide easily along the face of the fenders.

Product Specification:


Marine fenders typically operate as a group of single units where the type, location and density of their installation or deployment depends on several factors including their technical specifications, berth structure, ship type, etc.


 Product Name

Plastic Dock Cone Ship Fender Panel Board For Harbour Boat Protection Pads
 Material

ultrahigh molecular weight polyethylene



 Size




1220*2440mm, 1200*4000mm, 1250*3100mm, 2200*1000mm, other sizes can also be customized.


 Thickness

  5-200 mm


Density

  0.94-0.98 g/cm3



Water Absorption

<0.01%

Impact Strength


≥140 KJ/m2



Compressive Strength

≥42 Mpa

Friction coefficient 0.11-0.17




Customized Anti Impact Marine Fender Pad Uhmwpe / Hdpe 2
Customized Anti Impact Marine Fender Pad Uhmwpe / Hdpe 3

Customized Anti Impact Marine Fender Pad Uhmwpe / Hdpe 4

Application:


Because of the advantages, UHMWPE plastic Fender Panel is widely used in the world’s major ports and wharves.
1. Ships in the harbor
2. Chafing plate
3. Trucks drive piles first
4. Floating wharf
5. Slide the wall fender
6. Protection of quaywall
7. Protection of piles

Customized Anti Impact Marine Fender Pad Uhmwpe / Hdpe 5
